Features
| Locking 16A input power connector |
| 16A power loop-out connector |
| 3 x 13A sockets for peripheral devices |
| 2 x independent 4K HDMI channels |
| 2 x discrete 1Gb network connections |
| Robust, dust-proof Fibreco Mini HMA hermaphroditic connector |
| Integrated adjustable rigging points for use with standard Doughty couplers |
| Fully compatible with QED FibreStick and QED HDMI 2.0 TX/RX system |
| Multi colour LED status display |
Technical Specification
| 4K @60Hz RGB 4:4:4 up to 600m over multimode OM3 cable |
| Full HD @60Hz RGB up to 2500m over multimode OM3 cable |
| Resolution agnostic |
| Transparent EDID |
| Supports both HDCP 2.2 and 1.4 |
| Supports both HDMI 2.0 and HDMI 1.4 signals |
| Supports DVI 1.0 |
| No signal latency - zero frame delay |
| CEC support |
| High Dynamic Range (HDR) |
| CWDM technology for maximum bandwidth |
| Supports all embedded audio formats including PCM, Dolby Digital and DTS high-bitrate audio |
