Overview
The Roadster WU20K-J couples the benefits of xenon illumination – for the most natural colour accuracy and stability - with the next level of technology, performance and flexibility. With powerful standard features, such as Christie Twist™, liquid cooling and portrait display capabilities, the Roadster WU20K-J provides high performance and more lumens per watt in the smallest, most rugged chassis in its class.
Features
| WUXGA resolution (1920 x 1200) |
| 18,000 ANSI (20,000 centre) lumens |
| Embedded Christie Twist™ for image warping and edge blending |
| Variable contrast ratio of 1600-2000:1 Full Field | 650:1 ANSI for crisp, detailed images |
| 3.0kW xenon bubble lamp module |
| Comprehensive Color Adjustment (CCA™) |
| Dust-sealed engine |
| Intelligent Lens System (ILS) for zoom, focus, horizontal and vertical offset |
| Multi-windowing and screen processing (up to a 3x3 array) |
| Yellow notch filter (optional) |
| Setup lights help users see menu displays in low-light environments |
| Hybrid stacking |
| Built-in portrait capabilities |
| Liquid cooling allows for operating temperatures up to 40°C (104°) |
Technical Specification
| Image |
Brightness: 18,000 ANSI lumens, 20,000 centre lumens Contrast: 1600-2000:1 Full Field | 650:1 ANSI Uniformity: 80% brightness uniformity |
| Display |
Type: 3-chip 0.96" DMD Native resolution: WUXGA (1920 x 1200) |
| Lamp |
Type: 3.0kW xenon bubble lamp module Life: 750 hours typical lamp life |
| Inputs |
Analog Dual link DVI SD/HD-SDI Video Decoder Twin HDMI |
| Signals |
HDTV formats VGA through to QXGA (2048 x 1536) Accepts all current HDTV/DTV formats Multi-standard video decoder Horizontal and vertical scaling, all inputs |
| Pixel Clock | 165MHz |
| Scan Rates |
15kHz – 120kHz Horizontal 23.97Hz – 150Hz Vertical |
| Control & Networking |
RS232 In/Out RS422 In Ethernet (10/100) USB Device GPIO (RS232 9 Pin male connector) Built-in, backlit LCD keypad Remote control (with optional wired XLR connection) |
| Enhanced Feature Set |
Embedded Christie Twist™ Embedded image tiling Intelligent Lens System (ILS) Liquid cooling Advanced block artifact reduction ChristieNET ™ Web interface User-friendly, intuitive LCD keypad Advanced Loop-Thru twin HDMI card Set-up lights Lamp memory module User replaceable lamps Advanced, 10-bit processing Automatic shut off and ECO mode Dust-sealed light engine SNMP (simple network management protocol) DHCP (dynamic host configuration protocol) Hybrid stack Compatibility with legacy accessories |
| Power Requirements |
Operating voltage: 200V AC to 240V AC @ 50/60Hz Max current: 20A @200V Max power: 4000 W Dissipation: 13,650 BTU/hr |
| Dimensions |
Dimensions: (LxWxH): 815 x 621 x 419mm (32 x 24.5 x 16.5") Weight: 72.5kg (160lbs) (without lens) Shipping weight: 91kg (200lbs) |
| Operating Environment |
Temp: 5 – 40°C (40 – 104°F) Humidity: 20 – 80% noncondensing |
