Sanyo PLC-XF47

1024 x 768 resolution - 15,000 lumens

Overview

The Super High Brightness PLC-XF47 delivers a stunning 15,000 ANSI lumen output, an advancement which has been enabled in part by the use of inorganic LCD panels. These panels offer greater tolerance to Ultra Violet light, facilitating the development of brighter projectors with longer life cycles, as well as the achievement of higher contrast levels and improved image quality. The PLC-XF47 offers XGA resolution, with the same level of professional connectivity as its predecessors, matched with horizontal and vertical keystone correction and lens shift, as well full compatibility with a huge optional lens range and input boards. In addition, the PLC-XF47 achieves all this without the need for 3 phase power which is typically required by other projectors developing this level of light output. At less than 40Kg this combination of features offers huge flexibility for a range of applications.

Features

15,000 ANSI lumens with a 4-lamp system
XGA Resolution 1024x768
Contrast 2000:1
Impressive image homogeneity and lifelike colour reproduction
Horizontal and Vertical lens shift
11 interchangeable lenses
6 optional input boards

Technical Specification

Panel 3 x 1.8 " TFT p-Si (4:3)
Lamp 4 x 330 W NSH (LMP-109)
Brightness (ANSI lumens) 15000 ANSI lumens (eco mode 12000 ANSI lumens)
Lamp Service Life 3000hrs (eco mode) / 2000hrs (normal mode)
Fan Noise 51 dB (normal mode)
Contrast Ratio 2000:1
Resolution in pixels 1,024 x 768 (XGA)
Image size min-max (diagonal) 40" - 600"
Weight 80.5 lbs. (36.51 kg)
Uniformity 90%
Bandwith 230 MHz
Horizontal Frequency 15 - 120 kHz
Vertical Frequency 48 - 120 Hz
Colour Systems PAL, SECAM, NTSC, NTSC4.43, PAL-M/N
Connections Input 1: D-Sub15 (RGB), DVI-I (digital / HDCP)Input 2: Mini DIN 4-pin (S-Video), 5 x BNC (RGBHV / Composite / Y-Pb/Cb-Pr/Cr)Input 3: freely configurable with optional interface boards Input 4: freely configurable with optional interface boards Control
Horizontal Keystone Correction ±20%
Vertical Keystone Correction ±40%
HDTV Signals 480i, 480p, 575i, 576p, 720p, 1035i, 1080i
Computer Compatibility UXGA / SXGA+ / SXGA / WXGA / XGA / SVGA / VGA / MAC
Dimensions (WxHxD) 581mm x 252mm x 816mm
Weight 36.5kg
