Sanyo PLC-XF46

1024 x 768 resolution - 12,000 lumens

Features

3LCD™ Display Technology
12000 ANSI Lumens
1024 x 768 Native Resolution
4:3 Native Aspect Ratio
1300:1 Contrast Ratio
80.5 lbs

Technical Specification

Aspect Ratio 4:3 (Native), 16:9
Brightness (ANSI Lumens) 12000 ANSI Lumens
Contrast Ratio 1300:1
Display Type 1.8" Polysilicon TFT LCD x 3
Resolution (Native / Max) XGA (1024 x 768)
UXGA (1600 x 1200)
Video Compatibility PAL, SECAM, NTSC, NTSC4.43, PAL-M, PAL-N
Number of Colours 16.7 Million Colors
Dimensions (WxHxD) 22.9in. x 9.9in. x 30.8in. (58.17cm x 25.15cm x 78.23cm)
Weight 80.5 lbs. (36.51 kg)
Inputs 1 x DVI-I, 5 x BNC, 2 x RCA Video, 1 x S-Video, 1 x D-Sub 15pin
Control 1 x RS232, 1 x Serial, 1 x USB Type B
Power Supply 200 ~ 240 V / 50 ~ 60 Hz
Power Consumption 1700W (Normal), 20W (Standby)
Audible Noise 51 dB
Operating Temperature 41°F ~ 95°F (5°C ~ 35°C)
Lamp Type 300W UHP x 4
Lens Shift Vertical: 10:0 ~ 0:10
Projection Mode Front
Projection Screen Size (Diagonal) 40in. ~ 600in. (101.6cm ~ 1524cm)
Brightness Uniformity 90%
Dot Clock 230 Mhz
H-Sync Range 15 ~ 120 kHz
V-Sync Range 50 ~ 120 kHz
