Lightware MX16x16DVI-Plus

16x16 DVI matrix switcher

Overview

The 7 inch depth, 4 RU high body and low noise fan design makes it ideal for many space and noise sensitive applications. The frames incorporate Lightware's Advanced EDID Management function. The user can emulate any EDID on the switcher's inputs independently, read out and store any attached monitor's EDID in 100 internal memory locations, upload and download EDID files using Remote Control software. The crosspoint switcher can be controlled through a 9-pole D-sub connector via RS-232 or RS-422 protocol, and IP based Ethernet connection including web access through a Neutrik EtherCON connector which ensures a robust connection at all times.

Features

No switching latency - zero frame delay
Routing up to 16x16 DVI 1.0 signals
Routing HDMI 1.3 signals (with embedded audio) without HDCP
1920 x 1200 or 2048 x 1080 maximal resolution
Gold plated PCB boards and connectors
Built-in website
Front panel buttons control
Advanced EDID Management
RS-232 or RS-422 and Ethernet control
Vista Spyder and Barco Encore compatibility
Full crosspoint configuration (save and reload) as preset (32 presets)
Built-in power supply
